Encoder-Based Control: Precise movement control using an encoder-based system.
Magnetic Limit Switch Ready: Designed for easy installation of magnetic limit switches.
User-Friendly Control Board: The control board features terminal blocks, a display, and storage for up to 250 users, simplifying operation.
Safety Inputs: Safety inputs can be configured to directly control 8k2Ω resistive sensitive-safety edges for enhanced safety.
Self-Diagnosing Safety: Self-diagnosing safety devices ensure ongoing safety and reliability.
CONNECT Technology: Developed with CONNECT technology for remote digital control via a gateway or locally through CAME KEY.
Technical Specifications:
Power Supply: Control panel operates on 230V A.C. 50/60 Hz, while the motor power supply is also 230V A.C. 50/60 Hz.
Power Draw: Maximum draw of 2.6A with a power rating of 200W.
Maximum Torque: Offers a maximum torque of 24 Nm for robust performance.
Reduction Ratio: Utilizes a 1/33 reduction ratio for efficient operation.
Thrust: Provides a thrust of 300 N for moving gates effectively.
Maximum Speed: Achieves a maximum speed of 10 m/min for swift gate operation.
Duty Cycle: Operates with a duty cycle of 30%, ensuring reliability under frequent use.
Protection Rating: Features an IP54 protection rating for durability in varying conditions.
Insulation Class: Insulation class I enhances safety.
Lightweight: Weighing just 15 kg, it's easy to handle and install.
Motor Heat Protection: The motor is protected against overheating, with a threshold set at 150°C.
Condenser: Includes a 20 μF condenser for efficient operation.
