Operational Features:
- Video Standard: NTSC / PAL
- Scanning System: Progressive
- Image Sensor: 1/2.8” 2 Megapixel progressive CMOS
- Resolution: 1920 x 1080
- Minimum Illumination: 0.002 Lux / F1.5 (color, 30IRE), 0 Lux / F1.5 (IR ON)
- S/N Ratio: More than 45 dB
- Electronic Shutter Speed: 1/3 ~ 1/100000s
- IR Distance: Up to 40m (131 ft), depending on scene reflectance
- IR Light Control: Manual / Smart IR / OFF
- IR Light Number: 2
- Day/Night: Auto(ICR) / Color / B&W
- Backlight Compensation: BLC / HLC / WDR
- Wide Dynamic Range: 120 dB
- White Balance: Auto / Natural / Street Lamp / Outdoor / Manual / Customized Region
- Gain Control: 0~100
- Noise Reduction: 3D DNR
- Privacy Masking: Off / On (4 Areas, Rectangle)
- Motion Detection: Off / On (4 Zones, Rectangle)
- Region Of Interest: Off / On (4 Zones)
- Lens: 2.7 mm~13.5 mm, Motorized, F1.5
- Angle Of View: H: 109°
28°, V: 57°16°
- Alarm Input/Output: 1 In; 1 Out
Video Features:
- Compression: H.265 / H.264 / Smart Codec / MJPEG (Sub Stream)
- Resolution: Multiple options including 1080p and 720p
- Frame Rate: Up to 30 fps
- Bit Rate Control: CBR/VBR
- Bit Rate Range: H.264: 32 Kbps–6144 Kbps, H.265: 12 Kbps–6144 Kbps
- Analytics: Motion Detection, Video Tampering, Scene Changing, Tripwire Intrusion
Audio Features:
Network and Compatibility:
- Ethernet: RJ-45 (10/100Base-T)
- Protocols: HTTP, HTTPs, TCP, ARP, RTSP, RTP, RTCP, UDP, SMTP, DHCP, DNS, and more.
- Compatibility: ONVIF Profile S / G / Q / T
- Maximum Users Access: 20 users
- Security: User account and password protection, HTTPS, IP Filter, and more.
Electrical and Mechanical:
- Power Supply: DC12V, PoE (802.3 af)(Class 0)
- Power Consumption: <6.4W
- Dimensions: Ø122 mm x 88.9 mm (4.80’’x3.50’’)
- Product Weight: 0.50 kg (1.10 lb)
- Construction: Die-cast aluminum housing with powder coat
- Color: RAL 9003 (White)
Environmental and Regulatory:
- Operating Temperature: –30°C to 60°C (–22°F to 140°F)
- Relative Humidity: Less than 95%, non-condensing
- Ingress Protection: IP66
- Vandal Resistance: IK10
- Regulatory Compliance: FCC Part 15B, EN55032, EN 50130-4, UL 60950-1, EN 62368-1, EN 50581
